# Demo of Using twitter-hashtag-analytics to Analyze Tweets from #LAK13

### 2013-02-26

Building on Ben Marwick, Martin Hawksey and Tony Hirst’s work on analyzing tweets with R, I started an R project for tweet analysis, namely twitter-hashtag-analytics. This project is hosted on Github and welcomes anyone who’s interested to contribute. It is my very first attempt to write a package in R, so I admit the capabilities of it is still limited and its structure may be not properly planned. Any advice will be highly appreciated.

This demo, drafted with knitr, aims to show the functionality of twitter-hashtag-analytics and also available on Github. It will evlove along with this project

## Data Preparation

Before starting to analyze tweets, we will first load a few source files (libraries) in this project.

# check working directory
getwd()

# note that Knitr automatically sets wd to where the Rmd file is.  so if
# you wish to run code line-by-line, you should setwd mannually.

source("get_tweets.R")
source("munge_tweets.R")
source("utilities.R")


Then we can retrieve a Twitter hashtag dataset by searching through Twitter API. Two other methods of retriving tweets implemented in this project so far include retriving from Google Spreadsheet archives (see here) and reading directly from a CSV file.

# get tweets by search
# this function is defined in get_tweets.R
df <- GetTweetsBySearch('#LAK13')

# save or load data (so you can reuse data rather than search all the time)
save(df, file="./data/df.Rda")


This dataset contains 108 tweets posted by 52 unique Twitter users between 2013-02-19 and 2013-02-26.

Because tweet information retrieved through twitteR is kind of limited (see its reference manual, p. 11), we need to extract user information, such as reply_to_user and retweet_from_user, mannually from each tweet. At the same time, the names of metadata in twitteR are quite different from those used in the official Twitter API, the following PreprocessTweets function in munge_tweets.R also renames some attributes of tweets. Moreover, the PreprocessTweets function also trims urls in tweets and put them in a new column named links.

# preprocessing
df <- PreprocessTweets(df)

# structure of df
str(df)

## 'data.frame':    108 obs. of  14 variables:
##  $text : chr "Introducing Drake, a kind of 'make for data' from @factual: #lak13" "Getting more excited about pandas as i see it used RT @cteplovs: Using the pandas data analysis toolkit ...: #lak13" "Ryan Baker's talk on Educational Datamining at #lak13 was very interesting. I think the topic fits best with what I'm doing now"| __truncated__ "RT @sbskmi: #LearningAnalytics tutorials + practicals in #lak13 open course: Tableau, R + Evidence Hub " ... ##$ favorited   : logi  FALSE FALSE FALSE FALSE FALSE FALSE ...
##  $replyToSN : logi NA NA NA NA NA NA ... ##$ created_at  : POSIXct, format: "2013-02-26 19:35:58" "2013-02-26 19:10:04" ...
##  $truncated : logi FALSE FALSE FALSE FALSE FALSE FALSE ... ##$ replyToSID  : chr  NA NA NA NA ...
##  $id : chr "306487793666891776" "306481273315135489" "306479634164363264" "306479439598989312" ... ##$ replyToUID  : logi  NA NA NA NA NA NA ...
##  $statusSource: chr "&lt;a href=&quot;http://www.tweetdeck.com&quot;&gt;TweetDeck&lt;/a&gt;" "&lt;a href=&quot;http://www.tweetdeck.com&quot;&gt;TweetDeck&lt;/a&gt;" "&lt;a href=&quot;http://www.tweetdeck.com&quot;&gt;TweetDeck&lt;/a&gt;" "&lt;a href=&quot;http://twitter.com/&quot;&gt;web&lt;/a&gt;" ... ##$ screen_name : chr  "cteplovs" "cab938" "cbokhove" "dgasevic" ...
##  $from_user : chr "cteplovs" "cab938" "cbokhove" "dgasevic" ... ##$ reply_to    : chr  NA NA NA NA ...
##  $retweet_from: chr NA NA NA "sbskmi" ... ##$ links       : chr  "http://t.co/H6kJET9w2t" "http://t.co/Z0MKo85qqR" NA "http://t.co/baQ8yNlZqV" ...


## Start from Easy Stuff: Count Things

### Count tweets, retweets (by), and replies (to) for each user

Regular statuses, retweets, and replies are three main types of tweets we analyze. The GetTweetCountTable function can easily count total tweets sent by a user, times of retweeting by other users, and number of replies a user has received.

require(ggplot2)
require(reshape2)

# Count tables
countTweets <- GetTweetCountTable(df, "from_user")
countRetweets <- GetTweetCountTable(df, "retweet_from")

# quickly check distribution of tweets per user
qplot(countTweets$count, binwidth = 1, xlab = "Number of Tweets")  # combine counts into one data frame counts <- merge(countTweets, countRetweets, by = "user", all.x = TRUE) counts <- merge(counts, countReplies, by = "user", all.x = TRUE) colnames(counts) <- c("user", "tweets", "replied_to", "retweeted_by") counts[is.na(counts)] <- 0 # melt data counts.melt <- melt(counts, id.vars = c("user")) # plot (Cleveland dot plot) ggplot(counts.melt, aes(x = user, y = value, color = variable)) + geom_point() + coord_flip() + ggtitle("Counts of tweets, retweets, and messages") + xlab("Counts") + ylab("Users")  ### Ratio of retweets to tweets To get a sense how received or valued one’s tweets were within the community, we can further count the ratio of being retweeted by other users to sent tweets. # create new column 'ratio' counts$ratio <- counts$retweeted_by/counts$tweets

# plot ratio for users who have at least one rt
ggplot(counts[counts$retweeted_by > 0, ], aes(x = reorder(user, ratio), y = ratio)) + geom_point() + coord_flip() + ggtitle("Ratio of retweets to tweets") + xlab("Users") + ylab("Retweets/Tweets ratio")  ### Count URLs URLs embedded in tweets are important because they usually link to important resources that are of interest to this community. # count links countLinks <- GetTweetCountTable(df, "links") names(countLinks)[1] <- "url" # check top links head(countLinks[with(countLinks, order(-count)), ]) ## url count ## 1 https://t.co/1hj1FrD8 13 ## 2 https://t.co/8Di8QcKz 7 ## 3 https://t.co/cg9ItFZt 6 ## 4 https://t.co/EgtjcKoU6a 4 ## 5 https://t.co/jscpxQpfNA 3 ## 6 https://t.co/LnZsOCNFNs 2 # plot to see distribution of links ggplot(countLinks[countLinks$count > 1, ], aes(reorder(url, count), count)) +
geom_point() + coord_flip() + xlab("URL") + ylab("Number of messages containing the URL")


## Social Network Analysis (SNA)

### Visualize social networks

An archived tweet dataset contains retweeting and replying as two main type of links among users. Some studies looks into following relations, which require further queries to Twitter. So in this demo, we focus on retweeting and replying links.

The CreateSNADataFrame function in social_analysis.R provides an easy way to create a data frame containing all edges of the requested social network. With created edges, we can easily create an SNA graph and visualize it with packages like igraph and sna.

# load source file first
source("social_analysis.R")

# create data frame
rt.df <- CreateSNADataFrame(df, from = "from_user", to = "retweet_from", linkNames = "rt")

# begin social network analysis plotting
require(igraph)
require(sna)
require(Matrix)
require(SparseM)

# create graph data frame (igraph)
g <- graph.data.frame(rt.df, directed = TRUE)

# plot with igraph (quick and dirty)
plot.igraph(g)


# plot with sna get adjacency matrix
# convert to csr matrix provided by SparseM ref:
# http://cos.name/cn/topic/108758
mat.csr <- as.matrix.csr(mat, ncol = ncol(mat))

# plot with sna
gplot(mat.csr)


### Basic SNA measures

We can further compute some basic SNA measures. For instance, density of this network is 0.027, reciprocity of users in the network is 0.9488, and degree centralization of this network is 0.2425. These measures are calculated as below.

# density
gden(mat.csr)

## [1] 0.02703

# reciprocity
grecip(mat.csr)

##    Mut
## 0.9488

# centralization
centralization(mat.csr, sna::degree)

## [1] 0.2425


### Community detection

A regular task in SNA is to identify communities in a network. We can do it through the walktrap.community function in igraph package.

g.wc <- walktrap.community(g, steps = 1000, modularity = TRUE)

# number of communities
length(g.wc)

## [1] 7

# sizes of communities
sizes(g.wc)

## Community sizes
##  1  2  3  4  5  6  7
##  3  5 23  2  2  2  1

# plot
plot(as.dendrogram(g.wc))


We have detected 7 communities in this network. The largest community contains 44.231% of all users in this dataset.

### Univariate Conditional Uniform Graph Tests

In network analysis, people do types of tests to check whether some aspects of a network are unusual. We can do such tests, namely conditional uniform graph tests, through the cug.test function in the sna package. Further information about these tests can be found here.

# density
cug.gden <- cug.test(mat.csr, gden)
plot(cug.gden)


range(cug.gden$rep.stat) ## [1] 0.4531 0.5405 # reciprocity cug.recip <- cug.test(mat.csr, grecip) plot(cug.recip)  range(cug.recip$rep.stat)

## [1] 0.4495 0.5633

# transistivity
cug.gtrans <- cug.test(mat.csr, gtrans)
plot(cug.gtrans)


range(cug.gtrans$rep.stat) ## [1] 0.4537 0.5433 # centralisation cug.cent <- cug.test(mat.csr, centralization, FUN.arg = list(FUN = degree)) plot(cug.cent)  range(cug.cent$rep.stat)

## [1] 0.06156 0.22372


## Semantic Analysis

### Words

Firstly, make a word cloud.

# load source file first
source("semantic_analysis.R")

# construct corpus, with regular preprocessing performed
corpus <- ConstructCorpus(df$text, removeTags = TRUE, removeUsers = TRUE) # make a word cloud MakeWordCloud(corpus)  This task first uses ConstructCorpus in semantic_analysis.R to create a text corpus, and then uses MakeWordCloud to make a word cloud. Please note that ConstructCorpus provides a number of options such as whether to remove hashtags (#tag) or users (@user) embedded in tweets. Next we are going to create a term-document matrix for some quick similarity computation. # create a term document matrix only keep tokens longer than three # characters td.mat <- TermDocumentMatrix(corpus, control = list(minWordLength = 3)) # have a quick look td.mat ## A term-document matrix (292 terms, 108 documents) ## ## Non-/sparse entries: 746/30790 ## Sparsity : 98% ## Maximal term length: 17 ## Weighting : term frequency (tf) # frequent words findFreqTerms(td.mat, lowfreq = 10) ## [1] "activity" "analytics" "analyzing" "canvas" "capturing" ## [6] "data" "discussion" "feedback" "fritz" "john" ## [11] "join" "learning" "min" "network" "peer" ## [16] "recipes" "scale" "tools" "using" # find related words of a word findAssocs(td.mat, "learning", 0.5) ## min analytics feedback fritz peer scale join ## 0.74 0.72 0.66 0.66 0.66 0.66 0.62 ## using ## 0.59  For more advanced similarity computation among documents and terms, I am considering adding Latent Semantic Analysis (LSA) capability into this package in the future. ### Topic modelling with Latent Dirichlet Allocation (LDA) With the sparse term-document matrix created above, we can use the TrainLDAModel function in semantic_analysis.R to train a LDA model. (Note: I don’t understand all of steps in the code in TrainLDAModel refactored from Ben Marwick’s repo. So please help to check it if you understand LDA.) This step may take a while depending on the size of the dataset. # timing start ptm <- proc.time() # generate a LDA model lda <- TrainLDAModel(td.mat) # time used proc.time() - ptm ## user system elapsed ## 143.25 0.02 143.78  ThiS LDA model contains 25 topics. We can check keywords in each topic, get relevant topics of each tweet, and compute similarity scores among tweets based on topics they are related to. # get keywords for each topic lda_terms <- get_terms(lda, 5) # look at the first 5 topics lda_terms[, 1:5] ## Topic 1 Topic 2 Topic 3 Topic 4 Topic 5 ## [1,] "data" "example" "john" "data" "activity" ## [2,] "packages" "students" "research" "available" "signals" ## [3,] "scientist" "analytics" "activity" "example" "collaborate" ## [4,] "talk" "engange" "analyzing" "hub" "est" ## [5,] "educational" "learning" "capturing" "maybe" "hours" # gets topic numbers per document lda_topics <- get_topics(lda, 5) # look at the first 10 documents lda_topics[, 1:10] ## 1 2 3 4 5 6 7 8 9 10 ## [1,] 4 10 1 16 16 16 13 13 13 10 ## [2,] 14 13 24 1 1 23 4 4 4 19 ## [3,] 1 25 2 2 2 1 14 14 14 8 ## [4,] 2 1 3 3 3 2 2 2 2 18 ## [5,] 3 21 4 4 4 3 3 3 3 23 # compute similarity between two documents CosineSimilarity(lda_topics[, 1], lda_topics[, 10]) ## [,1] ## [1,] 0.7508 # computer a similarity matrix of documents sim.mat <- sapply(1:ncol(lda_topics), function(i) { sapply(1:ncol(lda_topics), function(j) CosineSimilarity(lda_topics[, i], lda_topics[, j])) }) # find most relevant tweets for a tweet index <- 1 ids <- which(sim.mat[, index] > quantile(sim.mat[, index], 0.9)) sim.doc.df <- data.frame(id = ids, sim = sim.mat[, index][ids]) sim.doc.df <- sim.doc.df[with(sim.doc.df, order(-sim)), ] # indices of most relevant tweets head(sim.doc.df$id)

## [1]  1 54 59 45 61 17


### Sentiment Analysis

This project implements three methods (with one method that depends on ViralHeat not working) of analyzing sentiment of tweets. Let’s try function ScoreSentiment in sentiment_analysis.R implemented based on this post.

# compute sentiment scores for all tweets
scores <- ScoreSentiment(df$text, .progress = "text") # plot scores ggplot(scores, aes(x = score)) + geom_histogram(binwidth = 1) + xlab("Sentiment score") + ylab("Frequency") + ggtitle("Sentiment Analysis of Tweets")  scores <- scores[with(scores, order(-score)), ] # check happy tweets as.character(head(scores$text, 3))
# check unhappy tweets
as.character(tail(scores$text, 3)) # check sentiment scores of tweets containing certain words create subset # based on tweets with certain words, e.g., learning scores.sub <- subset(scores, regexpr("learning", scores$text) > 0)
# plot histogram for this token
ggplot(scores.sub, aes(x = score)) + geom_histogram(binwidth = 1) + xlab("Sentiment score for the token 'learning'") +
ylab("Frequency")


Sentiment analysis with the sentiment package.

scores2 <- ScoreSentiment2(df$text) # plot scores. scale_x_log10 is used because the score is based on log # likelihood ggplot(scores2, aes(x = score)) + geom_histogram() + xlab("Sentiment score") + ylab("Frequency") + ggtitle("Sentiment Analysis of Tweets") + scale_x_log10()  # plot emotion qplot(scores2$emotion)


# plot most likely sentiment category
qplot(scores2$best_fit)  We can further check whether these two scores are correlated. # put them into one data frame scores3 <- data.frame(score1 = scores$score, score2 = scores2\$score)

# scatterplot with regression line
ggplot(scores3, aes(x = score1, y = score2)) + geom_point() + stat_smooth(method = "lm") +
xlab("Score by counting words") + ylab("Score from sentiment package")


Finally, this project is at its early stage. If you are interested, check out this twitter-hashtag-analytics repo on Github.

Update: Since I got a lot of emails about the post, I want to point out that I have converted most of the work here into a Shiny app, and you can find an updated version of the code in this “twitterytics-shiny” Github repo.
